Kaitec screw vacuum pump runs with high efficiency. Thanks to the patent design of flexible screw compressor, VP series vacuum pump consumes less energy by approximately 20% than other types of vacuum pump. Under the same Capacity, its main motor is one gear smaller than any other screw vacuum pumps.

Kaitec vacuum pump has maximum vacuum degree of more than 29.9inHg.

This allows the vacuum pump to be installed in any areas in need of stable and continuous vacuum application.

Forced lubrication of oil pump.

Microcomputer control panel.

Vacuum degree adjustment for the system.

Kerry air intake filter.

Kerry inlet valve.

Kerry oil filter.

Kerry8000 synthetic cooling liquid.

Energy saving motor.

Air cooling or water cooling.

Oil-gas separation pressure indicator.

High temperature shutdown protection system.

Emergency stop button.

Volume flow.

Technical Parameters of Kaitec Screw Vacuum Pump

Model	Volume flow m3/min	Motor power kW	Dimensions mm
VP11-7	6.851	11	1890x1230x1250
VP18-11	11.073	18.5	2040x1330x1410
VP30-18	17.91	30	2440x1660x1710
VP37-26	25.775	37	2610×1710×1810
VP55-40	39.35	55	2810×1960×1810
VP90-59	58.661	90	3200x2200x2100
VP160-97	96.885	160	4300x2400x2500
